REMOVING MISFEEDS

THE MACHINE

When a mark below blinks, a misfeed has occurred at that location.

X Automatic document feeder

Open the cover.

Remove the misfed original.

After removing the original,

close the cover.

Open the automatic document feeder.

Turn the conveyor roller in the direction

of the arrow.

Remove the misfed original.

Open the automatic document feeder

cover.

Press button (A) to release the

lock.

Automatic document

feeder

Transport unit

(page 34)

Transport area

(page 37)

Trays 1 to 4 (page 38)

(A)
