22

REMOVING MISFEEDS

7

Remove the misfed paper.

When released, the M6 lever

automatically returns to its

original position.

8

Open the cover.

9

Pull the M3 lever up in the direction of

the arrow.

10

Remove the misfed paper.

When released, the M3 lever

automatically returns to its

original position.

11

Close all covers.

X Stapler section

1

Open the cover.

See step 1 of "Transport area" (page 21).

2

Move the M4 lever in the direction of the

arrow.

3

Remove the misfed paper.

After removing the paper, return

the M4 lever to its original

position.

4

Move the M5 lever in the direction of the

arrow.

5

Remove the misfed paper.

After removing the paper, return

the M5 lever to its original

position.
