25

REMOVING MISFEEDS

4

Rotate the R2 knob in the direction of

the arrow.

5

Pull the R4 lever up in the direction of

the arrow.

6

Remove the misfed paper.

After removing the paper, return

the R3/R4 levers to their original

positions.

7

Push the R1 lever down in the direction

of the arrow.

8

Rotate the R2 knob in the direction of

the arrow.

9

Remove the misfed paper.

After removing the paper, return

the R1 lever to its original

position.

10

Move the R5 lever in the direction of the

arrow.

11

Remove the misfed paper.

After removing the paper, return

the R5 lever to its original

position.

12

Move the R6 lever in the direction of the

arrow.

13

Remove the misfed paper.

After removing the paper, return

the R6 lever to its original

position.
