REMOVING MISFEEDS

Detailed procedures for removing misfeeds are explained in this section. Use these procedures together with the

information screen.

MISFEED LOCATIONS

Misfeeds can be detected in the locations below.

In this manual, procedures for removing misfeeds are explained by device.

• Do not damage or touch the transfer belt while removing misfed paper.

• Be careful not to tear the misfed paper during removal.

• A misfeed may occur deep inside a compartment, so check the entire compartment carefully.

• If the paper tears, be sure to remove all pieces from the machine.

• After you have finished removing a misfeed, be sure to replace any covers or devices that were moved during misfeed

removal back in their original positions.

FINISHER (FOR

MX-M850) /

SADDLE STITCH

FINISHER

☞ page 24

BYPASS TRAY

(MX-MFX1) /

LARGE CAPACITY

TRAY

☞ page 43

FINISHER

☞ page 18

SADDLE UNIT

☞ page 21

INSERTER

☞ page 30

THE MACHINE

☞ page 33

BYPASS TRAY (MX-MFX2) /

LARGE CAPACITY TRAYS

☞ page 39

FOLDING UNIT

☞ page 28
