11. Options and peripheral devices
11 - 22
(b) Applicable tool
Servo amplifier side crimp terminals
Symbol
Crimp terminal Applicable tool Manufacturer
a
FVD5.5-S4
FVD5.5-6
YNT-1210S
b 8-4NS YHT-8S
JST
11.3.4 Dimensions
(1) FR-BU2 Brake unit
[Unit: mm]
FR-BU2-15K
Rating
plate
(Screw size: M4)
68
6 56 6
5
5 118
5
128
18.5
52 62
4
132.5
FR-BU2-30K
129.5
5
59
18.5
Rating
plate
52
(Screw size: M4)
128
55 118
5
108
6
6
96
