3. SIGNALS AND WIRING
3 - 28
(3) Encoder output pulses DO-2 (differential line driver type)
(a) Interface
Max. output current: 35 mA
150 ˖
100 ˖Am26LS32 or equivalent
Servo amplifie
r
LA
(LB, LZ)
LAR
(LBR, LZR)
SD
LG
High-speed photocoupler
Servo amplifie
r
LAR
(LBR, LZR)
SD
LA
(LB, LZ)
(b) Output pulse
˭/2
LAR
T
Servo motor CCW rotation
Time cycle (T) is determined by the settings of
[Pr. PA15] and [Pr. PC03].
LA
LB
LBR
LZ
LZR
400
˩s or more
(4) Analog output
LG
MO1
(MO2)
Servo amplifie
r
Output voltage: ±10 V
Maximum output current: 1 mA
Resolution: 10 bits or equivalent
Note. Output voltage range varies depending on the output contents. (Refer to section
5.3.3.)
