Panel Management and Option

2) Buttons

The buttons perform the following actions:

Name Description Relevant page

Add Panel Adds a new panel to be managed.

Below

AddGroup Adds a new group.

p.80

Edit Changesthecontentoftheselectedpanelorgroup.

Below,p.80

Delete Deletes the selected panel or group.

p.81

ManualControl Sets panels and control commands to be controlled manually.

p.81

Exit Closesthe[PanelManagement]window. -

●Adding/editing a panel

1. Click [Add Panel] to add a new panel to manage.

The[AddPanel(PanelPC)]dialogboxwillappear.

Click [Edit] to edit an existing panel.

The[EditPanel(PanelPC)]dialogboxwillappear.

 Thesettingsforthe[AddPanel(PanelPC)]and[EditPanel(PanelPC)]dialogboxesarethe

same. Panels can also be edited after they have been added.

2. Set the options.

1) Panelname(Compulsory)

 Chooseanamethatwillmakeiteasytoidentifythe

panel.(Namesmustbewithin50characters)

2) Group

 IntheGroupbox,selectagrouptoaddthepanelto.

If you do not want to assign the panel to any particular

group,select“(none)”.Panelsthatarenotassignedto

anyparticulargroupwillbeaddedunder“AllPanels”.

 Clicking[AddPanel]whilethe“Listofregistered

panel”treegrouporapanelassignedtoagroupis

selected will add the panel to the respective group.

3) HostnameorIPaddress(Compulsory)

 SetsthehostnameorIPaddressoftargetPCwhichcanbeaccessedfromtheserver.

It is not possible to create two or more panels with the same host name or IP address.

Managing panels
