Schedule Editor

Importing a schedule

TheimportfunctionisusedtoloadanexportedschedulethathasbeencreatedwiththisproductonanotherPC.

1. From the [File] menu, click [Import Schedule].

The[Selectthescheduletoimport]dialogboxwillappear.

2. Select a (.sch) le to import, and click [Open].

The[ImportSchedule]dialogboxwillappear.

A screen like the one on the right will appear while

theimportisbeingprepared.Click[Cancel]to

cancel the import.

3. Select the schedule folder in which the schedule is to be

saved.

4. Enter a “Schedule Name”, and click [Import].

If the same program name or timetable name

alreadyexistsonthePCwheretheimportistobe

used,aconﬁrmationdialogboxwillappear.Choose

whethertooverwritetheexistingﬁlesorimport

them under a new name.

5. Click [Yes].

The schedule will be saved with the name you entered.

The schedule import is now complete.

Creating a schedule
