Status Monitoring Tool

●Setting panels for which status will not be obtained

Itispossibletosetpanelsforwhichstatuswillnotbeacquiredsothattheywillnotbedisplayedinthepanellist.

1. From the [Option] menu click [Panel setting without status acquisition].

2. Select panels from the “Panel list with getting status”.

3. Click [Add].

Theselectedpanelswillmovetothe“Panellistwithout

gettingstatus”.

4. Click [OK].

 Toresetapanelsothatitsstatuswillbeacquired,

selectitfromthe“Panellistwithoutgettingstatus”,

andclick[Remove].

●Controlling target PC power

ThetargetPCcanbeturnedonandoff,andrestarted.

1. Select a group from the group tree, and then select a

panel from the panel list.

2. To turn the target PC on, from the [Panel] menu, click [Power control of controller PC] and then

[Power on], or alternatively, click

To restart the target PC, from the [Panel] menu, click [Power control of controller PC] and then

[Reboot], or alternatively, click

To turn the target PC off, from the [Panel] menu, click [Power control of controller PC] and then

[Power off], or alternatively, click

Aconﬁrmationdialogboxwillappear.

3. Click [Yes].

Theprocesswillbeexecuted.

Acquiring and displaying panel status
