9871 Tenth Edition 2-17
Emergency Power-Off Switches
LMU Power Switch
Note: Use the LMU power switch only in an emergency.
See Figure 2-6 for the location of the power switch.
Note: Some 9330 LMUs and 9315 EMs require a tool to open the front doors.
Contact Customer Support Services if the unit needs to be opened.
See the instructions at “Emergency Powering off” on page 3-3.
Figure 2-6. 9330 LMU Power Switch
C
4
0667
LMU
SERVICE
PANEL
POWER
SWITCH
(CB3)
POWER
INDICATOR
LIGHT
STAND-ALONE
LMU
