Tools, material and accessories
44 ProtoMat 95s/II
6.0 Tools, material and accessories
6.1 Tools
Tools for the LPKF
ProtoMat
95s/II have a diameter of 1/8 inch and two
different lengths.
Tools used to machine the material surface (milling and engraving) are
36 mm long while tools used for drilling or contour milling are 38 mm
long.
The following tools are available:
fig. 32: LPKF tools for circuit board
plotter
1
- LPKF Universal LPKF cutter for milling isolation channels and for engraving front plates
from 0.2 - 0.5 mm (depending on depth set). 36 mm long
2
- LPKF micro Cutter for milling 0.1 to 0.2 mm isolation channels (depending on depth set)
with a 17µm copper cladding on the base material. 36 mm long
3
- LPKF RF milling cutter for creating 0.25 mm or 0.4 mm wide
rectangular section isolation channels.
4
- Double-edged cutter (end-mill; 0.8 mm; 1 mm; 2 mm) for engraving front plates and for
engraving wider isolation channels. 36 mm long
5
- Twist drill of various diameters for drilling in base material. 38 mm long
6
- Contour cutter (1.0 mm; 2.0 mm) for milling out cut-outs in the base material. 38 mm long
31
56
2
4
