Video Driver Controls
C - 22 Attaching Other Displays
C
Attaching Other Displays
To Clone Displays:
1. Attach your external display to the external monitor port/HDMI-Out port, and turn it on.
2. Go to the Intel(R) HD Graphics Control Panel control panel and click Display >
Multiple Displays (sub-menu).
3. Click Clone from the Select Multiple Display Mode menu.
4. Click Apply, and OK to confirm the settings change.
5. You can select the displays to be used from the Select Active Displays menu.
Multiple Display
At least one other dis-
play must be attached in
order to view Multiple
Display selection op-
tions.
Figure C - 16
Display > Multiple
Displays (Clone)
