Appendix
Chapter 1 Scanner Overview
Glossary
Introduction
Index
Contents
TOP
18
How to Load
Documents
Configuring the
Scan Settings
How to Use the
Operator Panel
Various Ways to
Scan
Daily Care
Troubleshooting
Operational
Settings
Replacing the
Consumables
Scanner
Overview
■Back
USB connector
Used to connect a USB cable.
Security cable slot
Used to connect an anti-theft security cable (commercially available).
Ventilation port
Holes for ventilating hot air from inside the scanner.
Power connector
Used to connect the power cable.
"Power cable" refers to the AC cable and AC adaptor connected together.
EXT connector
Used to connect the imprinter.
The imprinter is used to print text (e.g. alphabets, numbers) on the scanned documents, and is
available as an option.
It can be useful for managing documents when you add a name, date or serial number on the scanned
document.
For details, refer to "A.4 Scanner Options" (page 214).
