Part of the image appears missing when using
the Carrier Sheet.
Did you place several small documents (e.g. photos,
postcards) in the Carrier Sheet for scanning?
Yes
Place only one document at a time in the Carrier Sheet.
No
Does the fold line of the document hang off the Carrier
Sheet?
Yes
Part of the image around where the document is folded may appear missing.
Place the document so its fold line is set about 1 mm inside from the edge of the
Carrier Sheet.
No
If the problem persists, check the items in "8.4 Before You Contact the Scanner
Service Provider" (page 159) first, then contact your FUJITSU scanner dealer or
an authorized FUJITSU scanner service provider.
