Chapter 6 Daily Care
Appendix
Glossary
Introduction
Index
Contents
TOP
110
How to Load
Documents
Configuring the
Scan Settings
How to Use the
Operator Panel
Various Ways to
Scan
Troubleshooting
Replacing the
Consumables
Scanner
Overview
Daily Care
Operational
Settings
Location and Frequency
Location Frequency
ADF Brake roller Every 5,000 sheets
Pick roller
Plastic idler roller
Rubber idler roller
Glass
Ultrasonic sensor
Document sensor
Feed roller
Eject roller
Flatbed
(fi-7260/fi-7280)
Document pad
Document bed
Plastic frame
ATTENTION
Cleaning cycles may vary depending on the condition of the documents.
Also, cleaning must be performed more frequently when the following
types of documents are scanned:
z Smooth-faced documents such as coated paper
z Documents with printed text/graphics that almost cover the entire
surface
z Chemically-treated documents such as carbonless paper
z Documents containing a large amount of calcium carbonate
z Documents written in lead pencil
z Documents on which the toner is not sufficiently fused
