P/N 11934-S11 1 of 4
Cirrus Design Section 9
SR20 Supplements
Pilot’s Operating Handbook and
FAA Approved Airplane Flight Manual
Supplement
for
L-3 Avionics Systems WX500
Stormscope Sensor
When the L-3 Avionics Systems WX500 Stormscope Sensor is
installed in the Cirrus Design SR20, this Supplement is applicable and
must be inserted in the Supplements Section (Section 9) of the Cirrus
Design SR20 Pilot’s Operating Handbook. This document must be
carried in the airplane at all times. Information in this supplement adds
to, supersedes, or deletes information in the basic SR20 Pilot’s
Operating Handbook.
• Note •
This POH Supplement Revision dated Revision 01: 07-18-05
supersedes and replaces the original release of this
supplement dated 04-12-00.
Revision 01: 07-18-05
