Press the [COLOR START] key ( )
or the [BLACK & WHITE START] key
().
Copying will begin.
If you are using the document glass to copy multiple original
pages, copying will take place as you scan each original. If you
have selected sort mode, change originals and press the
[START] key. Repeat until all pages have been scanned and
then touch the [Read-End] key. (For the second original and
following originals, use the same [START] key as you did for
the first original.
• If you selected printing in color, press the [COLOR START] key ( ). Even if a color is selected, pressing the
[BLACK & WHITE START] key ( ) will print the stamp items in black and white.
• If a color print setting is selected, the copy will be counted as a full color copy even if it is black & white.
To cancel scanning and copying...
Press the [STOP] key ( ).
To cancel Stamp...
Touch the [Cancel] key in the screen of step 3.
or
