13
How to Order an Electrode
(1) Choose Electrode Model.
If the electrode needs to fit an existing cable, check the cable con-
nector and note its color. If the cable connector is black and has an
S8 connector, use the F-615 or F-635 FermProbe. If the cable con-
nector is red or orange and has a K9 connector, use the F-695
FermProbe.
(2) Choose Elec trode Length.
If you have already chosen a housing, select an electrode length
with the same Class designation as the housing. For more i
nforma-
tion on
selection of housings, see pages 18–20. The housing order-
ing information box also lists the correct electrode length to order.
If you have not already chosen the housing, please review the rec-
ommendations next to each electrode model below.
(3) Confirm Cable Length and Connector.
Model F-615 pH electrodes require an S8 disconnect cable and
connector assembly. See pages 70 and 71
o r d e r i n g i n f o r m a t i o n
330
F-615
pH FermProbe
Housings for
standard 25mm
side ports
See page 24
320
336
326
Housings for
B. Braun Biotech
25 mm side ports
See page 26
H Electrodes pH Electrodes pH Electrodes pH Electrodes pH Elect
25 mm Side Port
Housings
Electrode UseWithThese Electrode Electrode
Model
Class
Housing Models Length Part Number
Model F-615 pH FermProbe with T-Pull Cap & S8 Disconnect Connector
F-615
A
320, 330, 326, 336, 350, 357, 370 130 mm F-615-B130-DH
F-615
B
320, 330 160 mm F-615-B160-DH
F-615
C
320, 330 210 mm F-615-B210-DH
Broadley-James Corporation (U.S. & Canada) Toll-Free: 800-288-2833 E-mail: sales@broadleyjames.com
C
M
Y
CM
MY
CY
CMY
K
13-T-pull_2013.pdf 1 8/11/14 10:11 AM
