189
7. Optional
Settings
7. Optional Settings
The optional settings allow you to customize the machine to better suit your
needs.
An initial setting has been made for each optional setting at the factory. To
change a setting, follow the steps below to display the optional setting, and
then select a new setting as explained in the pages that follow.
1
Press and then or
until OPTIONAL SETTING is selected in
the display.
2
Press .
3
Press the numeric keys to enter the 2-digit number (“01” to “38”) of the
optional setting that you wish to change. (Note: You can also press the
Rapid Key that has the same number as the optional setting.)
Example: Optional Setting 01
OR
Press or to scroll through the optional settings. When the
desired optional setting appears, press .
4
Enter a selection for the optional setting as explained in the following
pages.
5
After entering a selection, the subsequent option setting will appear in
the display. To return to the date and time display, press twice.
MENU
START/
ENTER
0
1
START/
ENTER
STOP
Display:
MENU MODE
1:RECEIVE MODE
2:LISTING MODE
3:ENTRY MODE
4: OPTIONAL SETTING
OPTIONAL SETTING MODE
01:
DEFAULT FAX RESOLUTION
02:# OF RINGS AUTO RX
03:# OF RINGS MANUAL RX
04: AUTO LISTING
