1-1
CHAPTER 1
BEFORE USING THE
PRODUCT
This chapter contains basic information that should be read before using
the product.
Page
INTRODUCTION..................................................................................... 1-2
MAIN FEATURES ................................................................................... 1-3
PART NAMES AND FUNCTIONS........................................................... 1-10
●
Exterior............................................................................................ 1-10
●
Interior............................................................................................. 1-11
●
Operation panel............................................................................... 1-13
●
Touch panel..................................................................................... 1-14
TURNING THE POWER ON AND OFF.................................................. 1-17
AUDITING MODE ................................................................................... 1-18
●
Using the machine when the auditing mode is enabled.................. 1-18
dragonII_copy_sec.book 1 ページ ２００６年１０月１８日 水曜日 午後７時３９分
