4-20
SPECIAL PAPERS
Special papers including transparency film, postcards and tabbed paper must be fed through the bypass tray.
1
Place the original in the document feeder
tray or on the document glass. (pages 4-3
to 4-6)
2
Load the special paper in the bypass tray.
See page 2-8 for the
specifications of paper
that can be used in the
bypass tray.
For the paper loading
instructions, see
"Loading paper in the
bypass tray" (page 2-6).
3
Touch the [PAPER SELECT] key.
4
Set the type and size of paper loaded in the
bypass tray.
The (X) key shows the
currently selected
paper type.
The (Y) key shows the
size of paper loaded
in the bypass tray.
To change the displayed paper type, touch the
(X) key before touching the (Y) key. When
loading paper, if you changed the paper size
from an AB size to an inch size (or from an inch
size to an AB size), or if you changed the paper
type, be sure to change the paper type and size
settings as explained in steps 5 to 7 on page 2-
10, and steps 8 to 10 on page 2-11.
5
Select the bypass tray.
6
Select any desired copy settings such as
the exposure or number of copies, and
then press the [START] key.
When copying from the
document glass in the
sort mode using the
[START] key, touch the
[READ-END] key after
all originals have been
scanned (step 8 on page
4-12).
UTO
AUTO
100%
A4
PAPER SELECT
OPY
EXPOSURE
4
AUTO
AUTO
100%
ORIGINAL
PAPER SELECT
COPY RATIO
EXPOSURE
0
N HEAVY PAPER
APER
N
PLAIN
5. A4
A4
(X) (Y)
1
2
3
AUTO
AUTO
100%
ORIGINAL
PAPER SELECT
COPY RATIO
EXPOSURE
0
N HEAVY PAPER
PAPER
N
PLAIN
5.
A4
A4
