SCANNER AND FAX FUNCTIONS

108

Storing destinations for Fax

Click [Destination] in the menu

frame of the Web page.

Click [Fax].

Enter the destination information.

For the settings, see the following table.

When you have completed all the entries, click [Submit].

The entries will be stored.

Fax Destination Control Information

Item Description

Name (Required) Enter the name of the destination (up to 20 characters).

Initial (Optional)

Enter initial text for the destinations (up to 3 characters). When

the destination list is displayed in the destination control

screen, the initial text is used to group the destinations.

This allows key assignment of the destination on the Fax rapid

key. (Enter figure among 1 to 18.) If it is left blank, certain

number is automatically assigned.

Fax No.

(Required)

Enter the Fax number to send Fax (up to 40 digits). Pause

(-"Hyphen") can also be entered.

Global Address

Link to "Global Address Search" when Corporate Address

Book is set. This button is not shown when LDAP is disabled.

Mode

Select Transmission Speed and International Correspondence

Mode for Fax transmission.
