TROUBLESHOOTING

MISFEED IN THE UPPER PAPER TRAY

Lift and pull out the upper paper tray

and remove the misfed paper.

Be careful not to tear the

misfed paper during

removal.

Open and close the side cover.

The misfeed indicator

( ) will go out.

Close the upper paper tray.

Push the upper paper

tray in completely.

Make sure that there is no misfed paper in the tray before pulling it out. (p.56)

Note

• When closing the side cover, press on the

handle.

• If the misfeed indicator ( ) does not stop

blinking, check for torn pieces of paper in

the machine.

Note

AL-1633_1644_EX.book 59 ページ２００３年１０月２３日　木曜日　午後８時２１分
