4 Replacement Procedures 4.3 Memory Module
4-12 [CONFIDENTIAL] Satellite A50S/TECRA A3X Maintenance Manual (960-534)
4. Open the left and right latches and remove the memory module.
Figure 4-4 Removing Memory Module
Memory Module
SLOT A: Standard Memory
Latch
SLOT B: Expansion Memory
Latch
